2.86" 376x960 IPS Bar TFT Module VXT286BZS-01 | Victronix

Designed for Narrow Embedded Interfaces
VXT286BZS-01 is a compact 2.86-inch bar-type IPS TFT module developed for telecommunications equipment, control panels and other embedded devices with limited installation width.

Its portrait display format is suitable for status information, menus, operating data and other vertically arranged interface content.

Product Highlights

Portrait Bar Format

The narrow active area supports compact equipment designs that cannot accommodate a conventional wide display.

IPS Viewing

IPS technology provides consistent image quality when the display is viewed from different operating positions.

Embedded Integration

SPI and 16-bit RGB interfaces support integration with compact controller-based equipment.

Selection Notes

Before selecting this module, please confirm:

• The controller supports the required SPI and RGB interface arrangement.
• The FPC exit direction, connector position and installation space match the equipment.
• The portrait orientation is confirmed before the enclosure design is completed.
• Grounding and shielding are reviewed at system level when higher ESD performance is required.

ESD-Oriented Custom Engineering

For equipment with demanding system-level ESD requirements, the display structure can be optimized together with the complete assembly. Available measures include increased FPC ground-copper coverage, conductive shielding tape and adjusted signal routing.

Final ESD performance should be verified with the complete equipment because the enclosure, grounding, controller board, cabling and installation structure all affect the result.

Typical Applications

Telecommunications equipment, compact control panels, handheld terminals, measuring instruments and other space-limited embedded systems.

General Specifications

Custom Options

FPC layout, connector, pin assignment, interface arrangement, backlight configuration and shielding requirements can be reviewed according to the customer's equipment design.

Capacitive touch, customized cover glass and bonding solutions can also be evaluated when a touch-enabled version is required.
