Custom TFT LCD Solutions for Industrial, Medical, Automotive and Smart Applications
What Is a TFT LCD Module
A TFT LCD (Thin-Film Transistor Liquid Crystal Display) is an active-matrix display in which each pixel is driven by its own thin-film transistor. Compared with passive matrix LCDs, TFT modules deliver faster response, higher contrast and more accurate color, making them the standard choice for industrial HMIs, medical instruments, automotive dashboards and smart home control panels.
How to Choose the Right TFT Module
1. Interface Type
Interface — the right choice depends on resolution, cable length and host hardware:
• SPI — minimal pin count and low cost, ideal for small panels under 3.5 inch and MCUs with limited I/O
• RGB (TTL) — simple parallel interface, easy to drive, the common choice for 3.5 to 7 inch modules
• LVDS — differential signaling with strong noise immunity, for long cable runs and resolutions up to 1080p
• MIPI DSI — high speed with low EMI, the standard for compact, mobile and battery-powered designs
• eDP — Embedded DisplayPort for high resolution panels (FHD and above); fewer lanes than LVDS, lower power and better EMI performance, suited to industrial PCs, medical monitors and large HMIs
• HDMI — plug-and-play via our converter board (HDMI to MIPI / LVDS), ideal for rapid prototyping with PCs, Raspberry Pi and single board computers
> Not sure which interface fits your host? Send us your board's interface spec — we will recommend a direct-match module or a converter board.
2. Panel type — TN for cost-sensitive projects, IPS for wide viewing angles and accurate color
3. Brightness — 300 to 500 cd/m² for indoor use, 800 cd/m² and above for sunlight readable outdoor equipment
4. Operating temperature — -20°C to +70°C as standard, -30°C to +85°C for harsh environments
5. Touch — resistive (RTP) or capacitive (CTP) with custom cover glass and bonding
Typical Applications
- Industrial HMI and control panels
- Medical monitoring and diagnostic devices
- Automotive dashboards and instrumentation
- Smart home wall panels and appliance displays
- Portable test and measurement equipment
Products
- View as
7 inch 800x480 High Brightness Wide Temperature TFT LCD Module 1000 cd/m2 LVDS - VXT700WHA-04
Victronix VXT700WHA-04: a high brightness wide temperature 7.0-inch 800 x 480 TFT LCD module, and two numbers define it. It delivers 1000 cd/m2 typical surface luminance from a 27-LED backlight at 27 V and 180 mA for the stated 4.86 W, putting it in daylight-readable territory, and it carries an operating range of -30 to +85 C with storage at -40 to +90 C. Driven by HX5281 over LVDS on a 40-pin 0.5 mm Hirose FH52-40S-0.5SH connector, it is transmissive and normally black with an ALL viewing direction, 16.7M colours, contrast 800 minimum and 1400 typical, response 25 ms typical and 35 ms maximum, uniformity 80 per cent minimum. ESD is the strongest in the range at 8 kV contact and 15 kV air. Brightness is stated at 1000-1100cd/m2.
Read MoreSend Inquiry
3.4" 800x800 Round TFT LCD Module High Brightness - VXT340MQIA-01
Victronix is a professional TFT module manufacturer and supplier in China. We have been in this field for 18 years and developed several models. This Victronix 3.4 inch 800x800 Round IPS TFT Module features 800×(RGB)×800 pixel resolution within an 87.6×87.6 mm active area, supporting up to 16.7 million colors for rich, detailed imagery. Combining exceptional optical performance with robust reliability, this display solution delivers crisp visuals across extreme operating conditions.
Read MoreSend Inquiry
3.9" 480x128 Bar Type TFT LCD Module 1000 cd/m2 Sunlight Readable- VXT039BPSA-02
This 3.9-inch 480x128 TFT module is a bar display — a 3.75:1 stretched panel, the only one of its shape in our range — and the brightest module we make at 1000 cd/m² typical. A narrow strip suits a line of text, a row of readouts or a status bar, and 1000 cd/m² keeps it legible under strong light. It is transmissive with 16.7M colours, an ST7282A driver and an ALL viewing direction, so mounting can be decided mechanically. A full frame is only 120 KB, so most microcontrollers need no external RAM. Rated -20 to +70°C.
Read MoreSend Inquiry
3.5" 320x240 Anti-Glare TFT LCD Module Wide Temperature - VXT350HQS-01X-W
The VXT350HQS-01X-W is a 3.5-inch TFT LCD module with 320x240 QVGA resolution and an anti-glare top polarizer — the only module in our range that specifies one. Combined with all-direction viewing and no grayscale inversion, it stays readable wherever the operator stands and wherever the light comes from, without spending brightness or backlight life on the problem. Rated -30 to +85°C, with 24-bit RGB for video and a separate SPI channel for configuration.
Read MoreSend Inquiry
4.3 Inch 480x272 High Brightness Wide Temperature TFT LCD - VXT430BPSA-04
The VXT430BPSA-04 is a 4.3-inch high-brightness TFT LCD module built for equipment that works outdoors or in harsh industrial environments. Two ratings define it: a bright backlight driven harder than standard, and a -30 to +80°C operating range that covers sealed enclosures in summer and unheated installations in winter. The brightness has a price — the same 16-LED array lasts 20,000 hours here against 50,000 in our standard-brightness module. Supplied without touch, with 24-bit RGB888 and 16 LEDs at 24 V.
Read MoreSend Inquiry
4.3" 480x272 RGB TFT LCD Module with Capacitive Touch - VXT430HPWA-03C
The VXT430HPWA-03C is a 4.3-inch TFT LCD module with 480x272 resolution and integrated capacitive touch, wired as two independent subsystems: the display runs on its own 40-pin interface and VDD rail, while the FT5446 touch controller has a separate 6-pin FPC and its own VDD-CTP supply. That lets you power the display down and keep touch alive, or reset touch without touching the display. Rated 850 cd/m² and -30 to +85°C, it suits outdoor handheld terminals, field instruments and portable equipment.
Read MoreSend InquiryWhy Source TFT LCD Modules from Victronix
Victronix has been designing and manufacturing TFT LCD modules for 20 years, supplying standard and custom displays to customers in industrial control, medical, automotive and smart home markets.
Wide Range, One Supplier
- Sizes from 0.96inch to 32inch
- Resolutions from QVGA to FHD
- Interfaces: SPI, RGB, LVDS, MIPI DSI, HDMI with converter board
- Panel options: TN, IPS, high brightness, transflective, bar type, round
Customization Built Around Your Project
- Custom FPC length, pinout and connector
- Resistive or capacitive touch panel integration
- Cover glass with custom printing, thickness and surface treatment
- Brightness upgrade and wide temperature design
- Interface conversion boards
Quality You Can Verify
Every module is tested for brightness, contrast, viewing angle and response time before shipment, and validated against thermal shock, humidity and vibration requirements. Our management systems are certified to ISO 9001, ISO 14001 and IATF 16949 within the scope of the applicable certificates.
From Sample to Volume
Standard samples ship in 15 working days. Engineering support covers datasheet, 3D drawing, interface definition and driver reference code. Low MOQ for prototypes, scalable capacity for volume production.
