High-Brightness TFT LCD Solutions for Outdoor and Strong-Ambient-Light Applications
Custom High-Brightness TFT LCD Solutions
Victronix provides high-brightness TFT LCD modules for industrial equipment, outdoor terminals, charging equipment, payment systems, transportation devices, medical equipment and other applications used under strong ambient light.
Display brightness can be evaluated according to the required screen size, application environment, power consumption, thermal design and viewing conditions. Available customization options include the backlight, interface, FPC, connector, operating temperature, touch screen, cover lens and mechanical structure.
For applications requiring improved outdoor visibility, high-brightness TFT LCD modules can be integrated with anti-glare cover lenses, optical bonding and suitable touch-screen solutions. Our engineering team supports display selection, optical evaluation, sample development, testing and mass production.
Applications of High-Brightness TFT LCD Modules
- Outdoor Terminals
- EV Charging Equipment
- Industrial Equipment
- Transportation Systems
- Payment TerminalsMedical & Monitoring Equipment
Products
- View as
7 inch 800x480 High Brightness Wide Temperature TFT LCD Module 1000 cd/m2 LVDS - VXT700WHA-04
Victronix VXT700WHA-04: a high brightness wide temperature 7.0-inch 800 x 480 TFT LCD module, and two numbers define it. It delivers 1000 cd/m2 typical surface luminance from a 27-LED backlight at 27 V and 180 mA for the stated 4.86 W, putting it in daylight-readable territory, and it carries an operating range of -30 to +85 C with storage at -40 to +90 C. Driven by HX5281 over LVDS on a 40-pin 0.5 mm Hirose FH52-40S-0.5SH connector, it is transmissive and normally black with an ALL viewing direction, 16.7M colours, contrast 800 minimum and 1400 typical, response 25 ms typical and 35 ms maximum, uniformity 80 per cent minimum. ESD is the strongest in the range at 8 kV contact and 15 kV air. Brightness is stated at 1000-1100cd/m2.
Read MoreSend Inquiry
3.4" 800x800 Round TFT LCD Module High Brightness - VXT340MQIA-01
Victronix is a professional TFT module manufacturer and supplier in China. We have been in this field for 18 years and developed several models. This Victronix 3.4 inch 800x800 Round IPS TFT Module features 800×(RGB)×800 pixel resolution within an 87.6×87.6 mm active area, supporting up to 16.7 million colors for rich, detailed imagery. Combining exceptional optical performance with robust reliability, this display solution delivers crisp visuals across extreme operating conditions.
Read MoreSend Inquiry
3.5" 320x240 Anti-Glare TFT LCD Module Wide Temperature - VXT350HQS-01X-W
The VXT350HQS-01X-W is a 3.5-inch TFT LCD module with 320x240 QVGA resolution and an anti-glare top polarizer — the only module in our range that specifies one. Combined with all-direction viewing and no grayscale inversion, it stays readable wherever the operator stands and wherever the light comes from, without spending brightness or backlight life on the problem. Rated -30 to +85°C, with 24-bit RGB for video and a separate SPI channel for configuration.
Read MoreSend Inquiry
4.3 Inch 480x272 High Brightness Wide Temperature TFT LCD - VXT430BPSA-04
The VXT430BPSA-04 is a 4.3-inch high-brightness TFT LCD module built for equipment that works outdoors or in harsh industrial environments. Two ratings define it: a bright backlight driven harder than standard, and a -30 to +80°C operating range that covers sealed enclosures in summer and unheated installations in winter. The brightness has a price — the same 16-LED array lasts 20,000 hours here against 50,000 in our standard-brightness module. Supplied without touch, with 24-bit RGB888 and 16 LEDs at 24 V.
Read MoreSend Inquiry
4.3" 480x272 RGB TFT LCD Module with Capacitive Touch - VXT430HPWA-03C
The VXT430HPWA-03C is a 4.3-inch TFT LCD module with 480x272 resolution and integrated capacitive touch, wired as two independent subsystems: the display runs on its own 40-pin interface and VDD rail, while the FT5446 touch controller has a separate 6-pin FPC and its own VDD-CTP supply. That lets you power the display down and keep touch alive, or reset touch without touching the display. Rated 850 cd/m² and -30 to +85°C, it suits outdoor handheld terminals, field instruments and portable equipment.
Read MoreSend Inquiry
4.3 inch 480x272 RGB TFT LCD Module VXT430BPI-01ND
The VXT430BPI-01ND is a 4.3-inch 480x272 industrial TFT LCD module with a standard RGB interface and ILI6485 controller. It delivers 16.7M colors, 300 cd/m2 brightness, a 700:1 contrast ratio and a 20 ms response time, backed by a 7S1P white LED backlight rated for 30,000 to 50,000 hours. Operating from -20°C to +70°C and RoHS compliant, it is built for industrial HMIs, automotive dashboards and medical monitoring devices. Custom FPC, touch panel and cover glass are available.
Read MoreSend InquiryNeed a High-Brightness TFT LCD Solution?
Tell us your required display size, resolution, target brightness, interface, operating temperature, touch function, viewing environment and application. Our engineering team will help evaluate a suitable high-brightness TFT LCD solution.
If the target luminance is unknown, you may send us the product application and ambient-light conditions for evaluation.
