Custom TFT LCD Solutions for Industrial, Medical, Automotive and Smart Applications
Products
- View as
6.86 Inch Bar-Type TFT LCD Display
The VXT686BZSA-01 is a 6.86-inch bar-type TFT LCD for elongated display layouts. With 16.7 million colors and wide viewing angles, the module provides space for status indicators, menu items and operating information in compact equipment panels.
Read MoreSend Inquiry
2.8 inch 240*320 Wide Temperature TFT Module
The VXT280GQSW-01 is a 2.8-inch wide temperature TFT LCD for compact equipment interfaces. A -30°C to +80°C operating range and selectable RGB, MCU or SPI communication modes give designers flexibility across different environments and host platforms.
Read MoreSend Inquiry
15.6 inch 1920x1080 IPS TFT LCD
The VXT156HX1B-01 is a 15.6-inch VA TFT LCD combining high static contrast with a Full HD widescreen format. Wide viewing angles, an anti-glare surface and dual-channel LVDS support integration into indoor monitors and information terminals.
Read MoreSend Inquiry
1.77 Inch Compact TFT LCD with MCU Interface
The VXT177SSI-02 brings color graphics to compact equipment with a 1.77-inch TFT display and an 8-bit MCU interface. Its small footprint provides an option for handheld instruments, portable devices and simple menu-based control panels.
Read MoreSend Inquiry
1.77 Inch 500 Nits SPI TFT LCD Display
The VXT177HSS-13 combines 500 cd/m² typical brightness with a 4-wire SPI interface in a compact 1.77-inch TFT LCD. An ST7735V driver and 12-pin connection make the module an option for embedded designs that prioritize display brightness and serial connectivity.
Read MoreSend Inquiry
12.1 inch 1280x800 sunlight readable IPS TFT Module
The Victronix VXT121BIHA-01 is a 12.1-inch WXGA (1280 x RGB x 800) IPS TFT LCD module designed for equipment that must stay readable in bright ambient light and keep running in harsh environments. Its IPS cell delivers stable color and contrast from every viewing direction with no grayscale inversion, while the 800 cd/m² high-brightness backlight keeps the screen legible under indirect and direct sunlight.
Read MoreSend InquiryWhy Source TFT LCD Modules from Victronix
Victronix has been designing and manufacturing TFT LCD modules for 20 years, supplying standard and custom displays to customers in industrial control, medical, automotive and smart home markets.
Wide Range, One Supplier
- Sizes from 0.96inch to 32inch
- Resolutions from QVGA to FHD
- Interfaces: SPI, RGB, LVDS, MIPI DSI, HDMI with converter board
- Panel options: TN, IPS, high brightness, transflective, bar type, round
Customization Built Around Your Project
- Custom FPC length, pinout and connector
- Resistive or capacitive touch panel integration
- Cover glass with custom printing, thickness and surface treatment
- Brightness upgrade and wide temperature design
- Interface conversion boards
Quality You Can Verify
Every module is tested for brightness, contrast, viewing angle and response time before shipment, and validated against thermal shock, humidity and vibration requirements. Our management systems are certified to ISO 9001, ISO 14001 and IATF 16949 within the scope of the applicable certificates.
From Sample to Volume
Standard samples ship in 15 working days. Engineering support covers datasheet, 3D drawing, interface definition and driver reference code. Low MOQ for prototypes, scalable capacity for volume production.
