High-Brightness TFT LCD Solutions for Outdoor and Strong-Ambient-Light Applications

The Victronix VXT121BIHA-01 is a 12.1-inch WXGA (1280 x RGB x 800) IPS TFT LCD module designed for equipment that must stay readable in bright ambient light and keep running in harsh environments. Its IPS cell delivers stable color and contrast from every viewing direction with no grayscale inversion, while the 800 cd/m² high-brightness backlight keeps the screen legible under indirect and direct sunlight.

The Victronix VXTL50BJZ-01 is a 21.5-inch TFT LCD module with a native 1920 x 1080 (FHD) resolution, a 16:9 aspect ratio and a 0.24795 mm pixel pitch, delivering sharp Full HD images. It provides 500 cd/m² typical brightness and 1000:1 typical contrast ratio, so content stays clear and consistent across a room. Video is carried by a dual-channel LVDS interface. An anti-glare top polarizer reduces reflections under indoor lighting.It suits digital signage, indoor kiosks, POS and self-checkout terminals, monitors, control rooms and light industrial HMIs. Touch panels, cover glass, HDMI/VGA/DP driver boards and higher-brightness options are available on request.

The Victronix VXT700WRA-01 is a 7.0-inch TFT LCD module with 800 x 480 pixel resolution and support for up to 16.7M colors, built for embedded and industrial equipment that needs a compact, easy-to-drive display. Its 24-bit parallel RGB interface with DE (data enable) and DCLK lets most mainstream MCUs and MPUs — STM32, NXP i.MX, Allwinner, Rockchip and similar — drive the panel directly from their on-chip LCD controller, with no LVDS serializer or bridge chip and no extra BOM cost. The module runs from a single 3.3 V logic supply, uses an RM53052 / RM57452 driver IC, and is rated for a -20°C to +70°C operating range, so it works in unheated enclosures and outdoor cabinets.

The Victronix VXT121BIHA-01 is a 12.1-inch WXGA (1280 x RGB x 800) IPS TFT LCD module designed for equipment that must stay readable in bright ambient light and keep running in harsh environments. Its IPS cell delivers stable color and contrast from every viewing direction with no grayscale inversion, while the 800 cd/m² high-brightness backlight keeps the screen legible under indirect and direct sunlight. The module fits industrial HMI panels, outdoor kiosks, EV charging piles, marine instruments, medical devices and agricultural machinery. Touch panels, cover glass, optical bonding and interface converter boards are available on request.

This Victronix 2.8inch 240*320 Projected capacitive touch IPS TFT Module combines a bright 240×320 IPS TFT panel (16.7M colors, 800 cd/m² brightness) with advanced 5-finger projected capacitive touch (≥6H hardness, ≥85% transparency). As a professional TFT module manufacturer and supplier in China, this Victronix 2.8inch TFT Module uses an industrial-grade design to provide superior application performance.

The Victronix 10.1-inch TFT LCD module pairs a 1024 x 600 widescreen resolution with a normally black LCD cell and a compact 40-pin interface, making it a practical fit for HMIs, control panels and embedded terminals that need more screen area than a 7-inch part without jumping to the cost and power of a large-format display. Normally black means each pixel blocks light when unpowered, so the panel rests at black rather than white — better contrast in dark UI states, no bright glow at the panel edges, and a fail-safe appearance if drive is lost.
