Custom TFT LCD Solutions for Industrial, Medical, Automotive and Smart Applications

View as

8.0 Inch 800x480 TFT LCD Module with Resistive Touch 18/24-Bit RGB - VXT800IWN-01P3-B

8.0 Inch 800x480 TFT LCD Module with Resistive Touch 18/24-Bit RGB - VXT800IWN-01P3-B

This Victronix 8 inch 800x480 TFT Module is a high-performance 8 inch TFT LCD module designed for industrial embedded systems. Featuring an 800×480 resolution (176.64 × 99.36 mm active area) with 0.2208 × 0.2070 mm pixel pitch, this module delivers sharp visuals and reliable operation in harsh environments. As a professional manufacturer and supplier of TFT modules in China, Victronix 8 inch TFT Module is fully compliant with ROHS environmental standards, ensuring superior application performance. We offer a customized service to meet the needs of our customers.
Read MoreSend Inquiry
8.0 Inch 800x480 TFT LCD Module 24-Bit RGB TTL - VXT800IWN-01

8.0 Inch 800x480 TFT LCD Module 24-Bit RGB TTL - VXT800IWN-01

This Victronix 8 Inch AT080TN64 LCD Display is a high-performance 8 inch TFT LCD module engineered for embedded systems requiring compact size, reliability, and vivid display quality. Featuring 800(RGB)×480 resolution within a compact 192.8×116.9×6.4mm footprint, this anti-glare display combines clarity with durability. It offers a typical brightness of 450 cd/m², wide viewing angles of 70° horizontal/50° vertical, and a contrast ratio of 500:1, ensuring excellent readability from various angles. Secondly, it supports a 24-bit RGB TTL interface with programmable scan direction (via U/D and L/R control pins) and DE/SYNC mode selection. Besides, it features an LED system with a lifespan of 20,000 to 50,000 hours , ensuring long-term use in various industrial applications. In addition, it is validated through thermal shock, humidity, vibration, and drop tests to operate reliably in extreme temperatures (-20°C to +70°C). For Industrial HMIs, medical devices, transportation systems, and embedded applications requiring sunlight-readable, shock-resistant displays with extended temperature operation.
Read MoreSend Inquiry
8.0 Inch 800x1280 Portrait TFT LCD Module MIPI DSI - VXT800BYH-01

8.0 Inch 800x1280 Portrait TFT LCD Module MIPI DSI - VXT800BYH-01

The VXT800BYH-01 is an 8.0-inch 800 x 1280 portrait TFT LCD module driven by an HX8260 over a 4-lane MIPI DSI interface on a 24-pin FPC, and the reason a panel this size ships on 24 pins is the interface. Four differential data lanes plus one differential clock pair carry what a 24-bit parallel RGB bus would need fifty pins to carry, so a 1,024,000-pixel display fits a host with a DSI peripheral and almost no other pins to spare. It is the most portrait panel here - 800 x 1280 in a 16:10 column - with square 0.13455 mm pixels at 188.8 PPI, 16.7M colours stated outright, and a diagonal of 203.09 mm that lands within 0.05 per cent of the nominal 8.0 inch. And TE is brought out on pin 4, which is the tearing effect output: with a 2.0 MB frame buffer too big to double cheaply, being able to stay single-buffered and still write tear-free is the difference between a workable design and an expensive one. Three things need settling before you commit. The logic voltage is stated two ways and they do not agree: pin 7 is annotated IOVCC 1.8V while the electrical table's supply-voltage-for-logic row gives 2.8 V typical, and the thresholds are written as fractions of VDD without saying which rail, so a 1.8 V host is either comfortably inside or well outside depending on which figure holds. The storage temperature runs -30 to +70 against an operating range of -20 to +70, so the high end is not wider at all - storage should be wider at both ends and here it is not. And the backlight's seven-in-series array is derived rather than stated, and it puts 27 mA through each string against a 30 mA absolute maximum.
Read MoreSend Inquiry
7.84 Inch 400x1280 Bar Type TFT LCD Module MIPI - VXT784BZE-01

7.84 Inch 400x1280 Bar Type TFT LCD Module MIPI - VXT784BZE-01

This Victronix 7.84 inch 400x1280 Bar IPS TFT Module is a high-performance 7.84 inch TFT LCD module designed for industrial embedded systems. Featuring a 400(RGB) × 1280 resolution and a 59.40 × 190.08 mm active area, this module delivers sharp, distortion-free images with a wide 160° viewing angle (H/V). The 400 cd/m² typical brightness and 900:1 contrast ratio ensure vivid readability even in challenging lighting conditions. As a professional manufacturer and supplier of TFT modules in China, Victronix 7.84 inch TFT Module is fully compliant with ROHS environmental standards, ensuring superior application performance. We offer a customized service to meet the needs of our customers.
Read MoreSend Inquiry
7.0 Inch 800x480 TFT LCD Module with Capacitive Touch 24-Bit RGB - VXT700SWH-03C

7.0 Inch 800x480 TFT LCD Module with Capacitive Touch 24-Bit RGB - VXT700SWH-03C

This Victronix 7 inch 800x480 Capacitive Touch TFT Module is a high-performance 7 inch TFT LCD module designed for industrial embedded systems. It features an 800×480 resolution screen, a capacitive touch panel (CTP), and a high-luminance backlight system within a compact form factor. As a professional manufacturer and supplier of TFT modules in China, this Victronix 7 inch TFT Module is fully compliant with ROHS environmental standards, ensuring superior application performance. We offer a customized service to meet the needs of our customers.
Read MoreSend Inquiry
7.0 Inch 800x480 Wide Temperature TFT LCD Module -30C to +85C 24-Bit RGB888 - VXT700QWH-26

7.0 Inch 800x480 Wide Temperature TFT LCD Module -30C to +85C 24-Bit RGB888 - VXT700QWH-26

This Victronix 7 inch Wide Temperature TFT Module is a high-quality 7 inch TFT-LCD module engineered for demanding industrial, automotive, and embedded applications. Combining exceptional optical performance with extreme environmental resilience, this module delivers uncompromising clarity and durability in harsh operating conditions. As a professional manufacturer and supplier of TFT modules in China, Victronix 7 inch TFT Module is fully compliant with ROHS environmental standards, ensuring superior application performance. We offer a customized service to meet the needs of our customers.
Read MoreSend Inquiry

Why Source TFT LCD Modules from Victronix

Victronix has been designing and manufacturing TFT LCD modules for 20 years, supplying standard and custom displays to customers in industrial control, medical, automotive and smart home markets.


Wide Range, One Supplier


  • Sizes from 0.96inch to 32inch
  • Resolutions from QVGA to FHD
  • Interfaces: SPI, RGB, LVDS, MIPI DSI, HDMI with converter board
  • Panel options: TN, IPS, high brightness, transflective, bar type, round

Customization Built Around Your Project

  • Custom FPC length, pinout and connector
  • Resistive or capacitive touch panel integration
  • Cover glass with custom printing, thickness and surface treatment
  • Brightness upgrade and wide temperature design
  • Interface conversion boards

Quality You Can Verify

ISO 9001, ISO 14001 and IATF 16949 management system certifications with a TFT LCD module

Every module is tested for brightness, contrast, viewing angle and response time before shipment, and validated against thermal shock, humidity and vibration requirements. Our management systems are certified to ISO 9001, ISO 14001 and IATF 16949 within the scope of the applicable certificates.

From Sample to Volume

Standard samples ship in 15 working days. Engineering support covers datasheet, 3D drawing, interface definition and driver reference code. Low MOQ for prototypes, scalable capacity for volume production.
