1.3 Inch 240x240 TFT LCD Module 3-Wire 9-Bit SPI / RGB / MCU - VXT130H2ZG-01

Where It Gets Used

• Wearable and body-worn devices — 1.53 mm and a square 240×240 face, with 188 PPI keeping fine type sharp.
• Handheld and portable field instruments — 112.5 KB fits a small microcontroller with no external RAM, and the reliability programme covers being carried and dropped.
• Round-bezel gauges, dials and instrument faces — a square panel under a circular mask is the standard GC9A01A form.
• Industrial HMI and machine control panels — a free viewing direction means no mounting orientation to get wrong, and 60 G shock is tested.
• Medical devices and portable monitors — thin, bright, and qualified for vibration and shock.
• Point-of-sale and payment terminals — a compact square display for a status face or a compact interface.
• Test and measurement equipment — square pixels keep scales, traces and dial graphics true.
• Vehicle dashboards and marine consoles — shock and vibration are tested on the bare module, which is what matters in a moving installation.
• Access control, intercom and door panels — a compact face in a small cut-out.
• Smart home control panels and thermostats — a square display for a radial control, at 450 cd/m².
• Microcontroller projects and retrofits — 112.5 KB fits internal SRAM, the serial interface needs four lines, and a 1.8 V host drives it directly.
• Products that must survive transport and field handling — the only module in this range with bare-module vibration, mechanical shock and drop all tested.

General Specification

Mechanical Drawing
