4.3 Inch 480x800 Portrait TFT LCD Module RGB888 - VXT430MBVS-03
The VXT430MBVS-03 is a 4.3-inch TFT LCD module with 480 x 800 pixels in portrait. The active area of 56.16 x 93.60 mm is taller than it is wide by an exact 5:3, matching the pixel count, and the pitch works out to 0.117 mm on both axes - square, so circles and dial scales need no correction. Pixel count is 384,000, identical to an 800 x 480 landscape panel: a portrait interface is a transposition of what you already have, and the frame buffer is the same 750 KB at RGB565. One detail saves a component. Logic IO runs from a separate 1.8 V rail, and with VIH at 0.7 IOVCC a 1.8 V host drives it directly - no level shifters, which is not the case on the 3.3 V IO modules elsewhere in this size. Images travel over 24-bit RGB with a real data-enable line, and the driver is configured over a 3-line serial interface, so both paths are on the one 45-pin FPC. Contrast carries a stated 700 minimum against 1000 typical, uniformity 80% minimum, and viewing angle 85 degrees in all four directions with no preferred orientation.
Read MoreSend Inquiry
4.3 Inch 480x272 TFT LCD Module 24-Bit RGB - VXT430INS-15
The VXT430INS-15 is a 4.3-inch 480 x 272 TFT LCD module built for products that get knocked about. Its reliability programme runs ten tests at 240 hours and includes the three most often missing at this size - 60 G mechanical shock on six faces, 6 hours of vibration across three axes, and ESD at 8 kV air and 4 kV contact - which is what makes it a panel for vehicles, mobile equipment and machine control rather than for a bench instrument. Brightness is quoted with a floor you can enforce at incoming inspection and a ceiling that shows the spread across a shipment, and both are rare at any price. Two things decide whether it suits your product. It is a TN panel: the specification states a 12 o'clock viewing direction, grey-scale inversion at 6 o'clock and unequal vertical angles, so do not mount it where the operator looks up at it - if your orientation is not under your control, an all-direction panel in this size is the better buy and we will say so. And the timing chapter is published only as diagrams, so ask us for the clock frequency and the porch values before you configure a controller.
Read MoreSend Inquiry
4.3 Inch 480x272 TFT LCD Module with Capacitive Touch 24-Bit RGB - VXT430CNH-07C
The VXT430CNH-07C is the capacitive-touch version of our 4.3-inch 480 x 272 panel, and the way it is put together is the reason to look at it. Touch is not squeezed onto the display FPC - it has its own 10-pin connector carrying I2C, reset and interrupt, so the 40-pin display bus stays clean and the two can be routed independently. The mechanical drawing documents the touch panel to a tenth of a millimetre, and the numbers show the touch view area sitting 0.40 mm outside the LCD active area on every side, so there is no dead band at the edges of the screen. Two things decide whether it suits your product. It is a TN panel: the specification states a 12 o'clock viewing direction, grey-scale inversion at 6 o'clock, and vertical viewing angles of 45 degrees one way and 60 the other, so mounting orientation has a right answer - and if your product is handheld or portable and the orientation is not under your control, a panel with no preferred direction is the better buy.
Read MoreSend Inquiry
3.95 Inch 480x480 Square TFT LCD Module RGB-18Bit + SPI - VXT400MCSA-03
Victronix is a professional TFT module manufacturer and supplier based in China. With 18 years of experience in this field, we have developed a variety of models. In addition to our standard products, we also offer customized services to meet our customers' specific needs. This Victronix 3.95 inch 480x480 IPS TFT Module is a high-performance 3.95 inch TFT LCD module designed for demanding industrial applications. With a resolution of 480×480 and a compact active area of 71.856 × 70.176 mm, this display features 262K colors, 400 cd/m² typical brightness, and an 800:1 typical contrast ratio to deliver outstanding visual clarity.
Read MoreSend Inquiry
4.0 Inch 320x240 TFT LCD Module 24-Bit RGB + SPI - VXT400HQI-01
TFT LCD is a type of liquid crystal display that utilizes thin-film transistor technology to enhance image quality, and it has numerous applications in everyday life. As a professional TFT module manufacturer and supplier in China, what makes the Victronix 4 inch 320x240 TFT Module different from other manufacturers? At first, it supports 350 cd/m² typical brightness, and a high typical contrast ratio of 500:1 with 50% NTSC color gamut to ensure consistent color and clarity Secondly, it integrates a backlight unit utilizing WHITE LED with a typical lifetime from 20,000 to 50,000 hours (to 50% initial brightness), ensuring clear visibility in all lighting conditions. Besides, it features a flexible SPI-3W serial interface and a 24-bit parallel RGB interface for versatile system integration.. Driven by the ILI9322 controller IC. In addition, it passes rigorous environmental testing, including high/low temperature operation/storage (-20°C to +70°C) and high humidity operation/storage (up to 50°C/85%RH) to operate seamlessly across an extended temperature range (-20°C to +70°C).
Read MoreSend Inquiry
3.97 inch 480x800 IPS TFT Module
This Victronix 3.97 inch 480×800 IPS TFT Module is a high-performance 3.97 inch TFT LCD module designed by Victronix for industrial, medical, and embedded systems. It features a 480×480 resolution IPS panel, providing crisp visuals, wide viewing angles, and intuitive user interaction in a compact form factor of 51.84×86.40 mm. As a professional manufacturer and supplier of TFT modules in China, Victronix 3.97 inch 480x800 IPS TFT Module is fully compliant with ROHS environmental standards, ensuring superior application performance. We offer a customized service to meet the needs of our customers.
Read MoreSend InquiryWhy Source TFT LCD Modules from Victronix
Victronix has been designing and manufacturing TFT LCD modules for 20 years, supplying standard and custom displays to customers in industrial control, medical, automotive and smart home markets.
Wide Range, One Supplier
- Sizes from 0.96inch to 32inch
- Resolutions from QVGA to FHD
- Interfaces: SPI, RGB, LVDS, MIPI DSI, HDMI with converter board
- Panel options: TN, IPS, high brightness, transflective, bar type, round
Customization Built Around Your Project
- Custom FPC length, pinout and connector
- Resistive or capacitive touch panel integration
- Cover glass with custom printing, thickness and surface treatment
- Brightness upgrade and wide temperature design
- Interface conversion boards
Quality You Can Verify
Every module is tested for brightness, contrast, viewing angle and response time before shipment, and validated against thermal shock, humidity and vibration requirements. Our management systems are certified to ISO 9001, ISO 14001 and IATF 16949 within the scope of the applicable certificates.
From Sample to Volume
Standard samples ship in 15 working days. Engineering support covers datasheet, 3D drawing, interface definition and driver reference code. Low MOQ for prototypes, scalable capacity for volume production.
