4.3 Inch 480x272 Portrait TFT LCD Module with Resistive Touch - VXT430TWH-06P

Victronix VXT430TWH-06P is a 4.3-inch TFT LCD module in portrait, and it carries a four-wire resistive touch panel. That combination is easy to overlook and hard to replace. A resistive panel responds to pressure rather than to a finger's conductivity, so it works with gloves, wet or oily hands, a stylus, or the tip of a tool, and it costs less than a capacitive stack — at the price of multi-touch, of 80% transmittance against the 85% a capacitive panel gives, and of a surface that takes a deliberate press. The shape suits a vertical column: the active area is taller than it is wide, so readings stack one per row, scrolling lists and status panels fit naturally, and a portrait enclosure needs no rework. The display itself runs 24-bit RGB on a 40-pin FPC from a single 3.3 V rail, and 130,560 pixels need only 255 KB of frame buffer — small enough that a microcontroller with 512 KB of internal SRAM needs no external RAM at all. Most optical figures carry a stated floor: 310 cd/m² minimum brightness, 400 minimum contrast, 80° minimum viewing angle. Two things want settling before you commit, and we set them out rather than leave them for bring-up: the specification writes the resolution as 480 × 272 while the geometry says the panel is 272 wide by 480 tall, and the driver IC is named two different ways in two different places.

Model:VXT430TWH-06P
